Germicidal UV Lamps
Victory Lighting germicidal lamps are highly efficient emitters of ultra-violet (253.7nm) light which has very effective germicidal properties and is being used as part of the drive to combat the current crop of infectious diseases.
Although the science behind germicidal UV has been around for a long time, it hasn't been used until recently. The use of UV systems is growing, which has seen new products entering the market place and these products are suitable for a whole range of industries, not just hospitals.
UV-C light is a germicidal, it deactivates the DNA of bacteria, virus and other pathogens and so destroys their ability to multiply and cause disease. UV-C light causes damage to the nucleic acid of micro-organisms by forming covalent bonds between certain adjacent bases in the DNA. The formation of these bonds prevents the DNA from replicating and when the organism tries to replicate, it can not and dies.
Studies are currently being held to assess the effectivity of UV light on COVID-19, but UV disinfection has already been seen to be successful on treatment on other Coronaviruses, such as SARS and MERS, which have similar characteristics.
Efficient, Simple Germ Control
- All lamps 253.7nm
- Ozone free quartz
- Hot cathode, pre-heat start
- 8000 hour average lamp life
- Tubular double ended with G5 or G13 base
- Single ended with 2G11 or G23 base (G23 has internal starter)
Germicidal Wave-Lengths
We currently Manufacture and sell dozens of Philips & Osram Lighting equivalent replacement ultraviolet lamps. Our Victory brand of ultraviolet lamps can be used as equivalent replacements for most manufacturers. If you can’t see the model number you need? Call us directly at 01525 487960, Mon. - Fri. or email us by using our contact form below.
| Type | Victory Ref. | Philips Ref. | Ozone Free | Tube Dia. mm | (A) mm | Watts | Base | Info |
|---|---|---|---|---|---|---|---|---|
| TL Mini | GUV4WD | 4W G5 | Yes | 15mm | 150mm | 4 | G5 | Info
|
| TL Mini | GUV6WD | 6W G5 | Yes | 15mm | 226mm | 6 | G5 | Info |
| TL Mini | GUV8WD | 8W G5 | Yes | 15mm | 303mm | 8 | G5 | Info |
| TL Mini | GUV10WD | 10W G5 | Yes | 15mm | 345mm | 10 | G5 | Info |
| TL Mini | GUV10WS-4P | 10W 4P SE | Yes | 15mm | 226mm | 10 | G10.2q | Info |
| TL Mini | GUV11WS-4P | 11W 4P SE | Yes | 15mm | 226mm | 11 | G10.2q | Info |
| TL Mini | GUV14WS-4P | 14W 4P SE | Yes | 15mm | 301mm | 14 | G10.2q | Info |
| TL Mini | GUV16WS-4P | 16W 4P SE | No | 16mm | 327mm | 15 | G10.2q | Info |
| TL Mini | GUV203T5LOF | N/A | Yes | 15mm | 217mm | 10 | G10.2q | Info |
| TL Mini | GUV203T5LO | N/A | No | 15mm | 217mm | 10 | G10.2q | Info |
| TL Mini | GUV436T5LOF | N/A | Yes | 15mm | 450mm | 21 | G10.2q | Info |
| TL Mini | GUV436T5LO | N/A | No | 15mm | 450mm | 21 | G10.2q | Info |
| T8 | GUV15WD | 15W G13 | Yes | 19mm | 451mm | 15 | G13 | Info |
| T8 | GUV20WD | 20W G13 | Yes | 24mm | 603mm | 20 | G13 | Info |
| T8 | GUV30WD | 30W G13 | Yes | 25mm | 908mm | 30 | G13 | Info |
| T8 | GUV40WD | 40W G13 | Yes | 25mm | 1213mm | 40 | G13 | Info |
| T8 | GUV55WD | 55W HO G13 | Yes | 25mm | 908mm | 55 | G13 | Info |
| PL-L | GUV18WS | 18W PL-L 4P | Yes | 17mm | 217mm | 18 | 2G11 | Info |
| PL-L | GUV24WS | 24W PL-L 4P | Yes | 17mm | 317mm | 24 | 2G11 | Info |
| PL-L | GUV36WS | 36W PL-L 4P | Yes | 17mm | 411mm | 36 | 2G11 | Info |
| PL-L | GUV40WS | 40W PL-L 4P | Yes | 17mm | 533mm | 40 | 2G11 | Info |
| PL-L | GUV55WS | 55W PL-L 4P | Yes | 17mm | 533mm | 55 | 2G11 | Info |
| PL-L | GUV60WS | 60W PL-L 4P HO | Yes | 17mm | 414mm | 60 | 2G11 | Info |
| PL-S | GUV5WS | 5W PL-S 2P | Yes | 12mm | 107mm | 5 | G23 | Info |
| PL-S | GUV7WS | 7W PL-S 2P | Yes | 12mm | 137mm | 7 | G23 | Info |
| PL-S | GUV9WS | 9W PL-S 2P | Yes | 12mm | 167mm | 9 | G23 | Info |
| PL-S | GUV11WS | 11W PL-S 2P | Yes | 12mm | 237mm | 11 | G23 | Info |
| PL-S | GUV13WS | 13W PL-S 2P | Yes | 12mm | 186mm | 13 | G23 | Info |
| T5 | GUV 36T5 HO 4P SE | 36T5 HO 4P SE | Yes | 16mm | 853mm | 75 | 4 Pins Single Ended | Info |
| T5 | GUV 36T5 HE 4P SE | 36T5 HE 4P SE | No | 16mm | 853mm | 40 | 4 Pins Single Ended | Info |
| Amalgam XPT System | GUV130WXPT | 130W XPT | Yes | 19mm | 842mm | 140 | 4 Pins Single Ended | |
| Amalgam XPT System | GUV180WXPT | 180W XPT | Yes | 19mm | 1032mm | 180 | 4 Pins Single Ended | |
| Amalgam XPT System | GUV200WXPT | 200W XPT | Yes | 19mm | 1147mm | 200 | 4 Pins Single Ended | |
| Amalgam XPT System | GUV325WXPT | 325W XPT | Yes | 19mm | 1582mm | 280 | 4 Pins Single Ended | |
| Amalgam XPT System | GUV325WXPTHO | 325W XPT HO | Yes | 19mm | 1582mm | 325 | 4 Pins Single Ended | |
| Amalgam XPT System | GUV260WDIMXPT | 260W DIM XPT | Yes | 32mm | 1514mm | 235 | Double Ended | |
| Amalgam XPT System | GUV330WXPT | 330W XPT | Yes | 32mm | 1554mm | 325 | Double Ended | |
| Amalgam XPT System | GUV335WXPTSE | 335W XPT SE | Yes | 32mm | 1514mm | 300 | Double Ended | |
| Amalgam XPT System | GUV335WWPXPTSE | 335W WP XPT SE | Yes | 32mm | 1514mm | 300 | Double Ended |
UV-C disinfection is very versatile and works on several harmful viruses, bacteria, moulds and spores. By using UV light in this manner, it can be applied to a whole range of applications.
Applications
- Hospitals / Medical Applications
- Leisure & Retail Venues
- Manufacturing Sites
- Gyms
- Blue Light Services
- Public Transport
- Education Facilities
- Hotels
- Transport Hubs
- Industrial Water Treatment
- Offices
- Domestic
